Gear Reducer Stepper Motor

60HSP NEMA24 HSP Planetary Gear Reducer

Stepper motors coupled with planetary or eccentric gearboxes — multiplying output torque and lowering speed for dosing, valve and positioning tasks.

60HSP NEMA24 HSP Planetary Gear Reducer

Datasheets & Drawings

Key specifications

FramesNEMA 11 / 17 / 23 / 24 / 34
Gearbox typesPlanetary (HSP), Eccentric (HSG), Precision Planetary (HSPLF)
Reduction ratios3 : 1 up to 125 : 1
BenefitHigher output torque at lower speed

NEMA 11–34 frames with planetary / eccentric gearboxes. Exact ratios and torque per model in the datasheet.
